Masibus LC5248E-AT User Manual

Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 22 of 44
6.6 CONFIGURATION MODE
CT
(Ct)
Cycle Time
Adjust Cycle Time
For, SSR o/p: (1 – 60 sec)
Relay o/p: (10 – 300 sec)
10
O.DIR
(o.dir)
Output Direction
Set Output Direction dir/rev
0 : REV (REVERSE)
1 : DIR (Direct)
0 (R E V )
Control Type(COP)
is P or PI or PID
MR
(mr)
Manual Reset
Adjust Manual Reset Value
It is used to shift P Band for critical Controlling
situations.
-50% to 50% of PB
EX. If PB = 50, SP = 100, O.DIR = REV
MR = 0MR = 25
PV
% POWER
PV
%POWER
<= 75
100 %
<= 100
100 %
100
50 %
125
50 %
>= 125
0 %
>= 150
0 %
0
Control Type(COP)
is P or PI or PID
ALPH
(alpH)
Sampling Rate
Adjust Sampling Rate
Its acts like Derivative Factor. It is used to decrease
effect of D term in PID output for some critical
operating condition
0.01 to 1.00
1 . 0 0
Control Type(COP)
is PID
SMP
(smp)
Sampling Period
Set Sampling Period. 200 /500 /1
0 : 200 ms
1 : 500 ms
2 : 1 sec
0
(200 ms)
Control Type(COP)
is PID
RAMP
((Ramp))
Ramp Rate type
n o n e /m i n . r /hr.r
0:none
1:min.r
2:hr.r
No n e
-
Rmp.R
((rmp.r)
Ramp rate value
0.1 to 999.9 Degree per minutes or hour
0 . 1
-
SOK.R
(SOK.R)
Soak rate
0.00 to 99.59 HH.MM
0.00
-
SOK.T
(SOK.T)
Soak type
s.hod/s.rst
0:s.hod
1:s.rst
s.rst
-
M.TIM
(m.tim)
Motor Travel
Time
10 to 500 sec
60
Output type is
VPFN
db
(db)
Dead Band
0.1 to 50.0
1 . 0
Output type is
VPFN
CONFIG URAT IO N PARAME TE RS
Parameter
(PV d isplay)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
INPT
(inpt)
INPUT Type
Set PV Input Type
tC e/tC j /tC K /tC t /tC b /tC r /tC s
/rtd.1 /rtd/0-5v /1-5v / 0-10
Value
Input Type
Range
0
TC E
-200 to 1000 °C
1
TC J
-200 to 1200 °C
TC E
