Masibus LC5248E-AT User Manual

Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 23 of 44
2
TC K
-200 to 1372 °C
3
TC T
-200 to 400 °C
4
TC B
450 to 1800 °C
5
TC R
0 to 1768 °C
6
TC S
0 to 1768 °C
7
RTD.1
-199.9 to 850.0 °C
8
RTD
-200 to 850 °C
9
0-5 V / 0-20 mA*
-1999 to 9999
10
1-5 V / 4-20 mA*
11
0-10 V
*Use external 250ohms,0.1% for current input
ZERO
(zero)
Zero
Automatically change to the Input Lower Range with
changing of Input Type
(Refer Above Table)
Can be set to any value within the Input Range & less
the SPAN Value.
-200
(If TC E)
SPAN
(span)
Span
Automatically change to the Input Higher Range with
changing of Input Type
(Refer Above Table)
Can be set to any value within the Input Range &
greater the ZERO Value.
1000
(If TC E)
OFST
(ofst)
offset
Offset Value
Input type
range
RTD/ Thermocouple
-100.0°C to +100.0°C
Linear
-1000 to +1000
0.0
FLTR
(fltr)
Filter
Enable or Disable Filter for PV Input
yes /no
0 : NO
1 : YES
1
(YES)
TSP1
(tsp1)
Type of Set Point
Set Type of Set Point
l-on/H-on
0 : L-ON (Lower ON)
1 : H-ON (Higher ON)
Refer ON-OFF Control on Page:32
0
(L- O N)
Control Type
(COP) is ON-OFF.
OPES
(opes)
OPEN Sensor
Status
Set Control O/P & Retransmission state when Input
OPEN condition.
down/up
0 : DOWN
1 : UP
Refer Page:44
1
(UP)
RD1
(rd1)
Relay Delay
(For Relay-1)
Relay Delay is amount of time (in sec), that Relay will
wait before getting ON after the ON condition occurs.
1 to 99 sec
1 se c
Control Type
(COP) is ON-OFF.
HY-1
(Hy-1)
Hysteresis – 1
(For Relay-1)
Hysteresis Value (in °C) for Relay-1 during ON-OFF
type Control.
1 to 100
TC & RTD Input
0.1 to 100.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 100.0
Linear Input with DP=1
0.01 to 10.00
Linear Input with DP=2
0.001 to 1.000
Linear Input with DP=3
1
Control Type
(COP) is ON-OFF.
