Masibus LC5248E-AT User Manual

Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 39 of 44
10.3 Exceptional Response
TABLE– 8
CODE
MEANING
01
Function code Invalid. It must be 01, 05, 03 or 06.The function code received in the query is
not allowable action for the slave.
02
Illegal address value. The data address received in the query is not an allowable address for the
salve.
03
Illegal data value. A value contained in the query data field is not an allowable value for the
salve.
06
When Master device write some parameters to Slave device, If slave device busy
then it will send 06 code to indicate slave device is busy.
Note:
1. Refer Menu Mode Description Table the value & Range of each
Parameter.
EX: Input Type (Applicable Range: 0 to 11):
Input Type
Value
E-tc
0
J-tc
1
K-tc
2
T-tc
3
B-tc
4
R-tc
5
S-tc
6
RTD 0.1 degree
7
RTD 1 degree
8
0 – 5V
9
1 – 5V
10
0 – 10V
11
