6.7 CALIBRATIONMODE
Set Logic for Alarm-2
norm /flsf
0 : NORM (Normal)
1 : FLSF (Fail-Safe)
Alarm Delay is amount of time (in sec), that Relay-1
will wait before getting ON after the alarm condition
occurs.
1 to 99 sec
Output Type is
LIN(Linear)
Alarm Delay is amount of time (in sec), that Relay-2
will wait before getting ON after the alarm condition
occurs.
1 to 99 sec
Auto Cold Junction
Compensation
Select Auto Cold Junction Compensation required or
not for TC input Type.
no /yes
0 : NO
1 : YES
Fix cold junction
Compensation
Set Fix cold junction Compensation value.
0 to 60.0 °C
Input Type is TC &
A.CJC is NO
Select A/M or Soak time
A-M/SOK.T
0 : A-M
1 : SOK.T
Control output
type is PID
Set Device Password
0 to 9999
Shows the Version of the Current Firmware
CAL IBRATIO N PAR AM ETE RS
Setting Name & Description
Calibration Zero for PV Input
(SV Display : PV)
Calibration Span for PV Input
(SV Display : PV)
Calibration Zero for Retransmission Output-1
(SV Display : If voltage:-0.000
If Current:-4.000)
Calibration Span for Retransmission Output-1
(SV Display : If voltage:-8.000
If Current:-20.00)
Calibration Zero for Retransmission Output 2
(SV Display : If voltage:-0.000
If Current:-4.000)
To Next Page
