Masibus LC5248E-AT User Manual

Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 25 of 44
* R.D-2
(r.d-2)
Retransmission-2
Direction
Set Direction for the Retransmission Output-2
rev /dir
0 : REV (REVERSE)
1 : DIR (DIRECT)
1
(DIRECT)
OT
(ot)
Output Type
Output Type
rely /ssr/lin
0 : RELY (Relay)
1 : SSR (Voltage Pulse Output)
2 : LIN (Linear)
3 : VPFN (Motor position control without slide wire
feedback)
Device can support RELAY or SSR output once at a
time. (Factory Settable)
** Device can support Control output type PID or
onoF.(Factory Settable)
0
(Relay)
**VPFN, LIN and
SSR option will not
appear if
COP(Control Type)
is ON-OFF
COP
(Cop)
Control Output
Type
Select Controlling Type for Output
P /Pi /pid
0 : P (Proportional Control)
1 : PI
2 : PID
0
(P Type)
Control output
type is PID
CO.LO
(Co.Lo)
Control Output
Low Limit in %
Control Output Low Limit in %.
0.0 to 100.0 %
(It will be always less then CO.HI)
0 . 0
Control output
type is PID
CO.HI
(Co.Hi)
Control Output
High Limit in %
Control Output High Limit in %.
0.0 to 100.0 %
(It will be always greater then CO.LO)
1 0 0. 0
Control output
type is PID
A1TP
(a1tp)
Alarm Type – 1
Refer ALARM Type Table on Page.39
0 to 15
6
(PV.A.L.)
Output Type is
LIN(Linear)
A2TP
(a2tp)
Alarm Type – 2
Refer ALARM Type Table on Page.39
0 to 15
6
( PV.A.L.))
Output Type is not
VPFN
A1HY
(a1HY)
Alarm 1 Hysteresis
Set Hysteresis(in °C) for Alarm-1
1 to 100
TC & RTD Input
0.1 to 100.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 100.0
Linear Input with DP=1
0.01 to 10.00
Linear Input with DP=2
0.001 to 1.000
Linear Input with DP=3
1
Output Type is
LIN(Linear)
A2HY
(a2Hy)
Alarm 2 Hysteresis
Set Hysteresis(in °C) for Alarm-2
1 to 100
TC & RTD Input
0.1 to 100.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 100.0
Linear Input with DP=1
0.01 to 10.00
Linear Input with DP=2
0.001 to 1.000
Linear Input with DP=3
1
Output Type is not
VPFN
A1LC
(a1lC)
Alarm 1 Logic
Set Logic for Alarm-1
norm /flsf
0 : NORM (Normal)
1 : FLSF (Fail-Safe)
Page. 37 shows operation diagram of different alarm Type for
Alarm Logic NORM (Normal). For Fail-Safe Logic Alarm will
work completely opposite to Normal behavior. (i.e. for any
particular condition when Relay is ON for Normal logic, for
that condition relay will OFF for Fail-Safe Logic & vice-versa)
0
(Normal)
Output Type is
LIN(Linear)
