Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 24 of 44
Set position of Decimal Point on Display.
0 /0.0 /0.00 /0.000
*0 : 0
*1 : 0.0
2 : 0.00
3 : 0.000
Input Type is
Linear,
*if input type is
RTD or TC
Set which Set Point to shown in SV display in RUN
mode while device is in Auto Mode
C1.sp /A2.sp /A1.sp / Sok.t
0 : C1.SP (Control Set Point 1)
1 : A2.SP (Alarm Set Point 2)
2 : A1.SP (Alarm Set Point 1)
3: SOK.T (Remaining soak time)
Output Type is
Relay or SSR then
A1.SP will not
appear.
Adjust Brightness of the 7-segment Display.
10 to 100
Unit ID for Modbus-RS485 Communication
1 to 247
Set Modbus RS485 Communication Baud Rate
9600 /19.2k /38.4k
0 : 9600 (9600 bps)
1 : 19.2K (19200 bps)
2 : 38.4K (38400 bps)
Retransmission-1 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v /1-5v /0-10v /4-20 /0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable from the Hardware.
Retransmission-1
Direction
Set Direction for the Retransmission Output-1
rev /dir
0 : REV (REVERSE)
1 : DIR (DIRECT)
EX. If i/p is RTD.1,ZERO=0,SPAN=600, RTR.1=4-20mA&
RT.D.1=DIR
when PV = 0, RTR o/p = 4mA
PV = 300, RTR o/p = 12mA
PV = 600, RTR o/p = 20mA
RT.D.1=REV
when PV = 0, RTR o/p = 20mA
PV = 300, RTR o/p = 12mA
PV = 600, RTR o/p = 4mA
Refer Retransmission o/p table on Page 44 for more info.
OT(Output Type)
is Relay / SSR
Retransmission-2 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v /1-5v /0-10v /4-20 /0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable from the Hardware.
