What to do if the Masimo SET Radical-7 display does not rotate manually?
If the display on your Masimo SET Medical Equipment does not rotate manually, check for flex interference and replace the Swivel Connector if needed. If the issue continues, replace the Keypad or the Portable System Board.
What to do if the Masimo SET Radical-7 Medical Equipment has a power fault?
If your Masimo SET Medical Equipment has a power fault, replace the external Power Cable. If the problem persists, check the fuses at the AC Input Filter. Also, check the 12VDC power. If these steps do not resolve the issue, replace the Docking Station System Board.
Why does the Masimo SET Medical Equipment docking station fail when the portable is docked?
If the Masimo SET Medical Equipment docking station fails when the portable is docked, ensure the software of the Handheld and Docking Station is compatible. If this is not the issue, replace the Portable System Board, or the Docking Station System Board. Also, check the Interface Cable and replace if necessary.
What to do if the Masimo SET Medical Equipment fan does not function?
If the fan on your Masimo SET Medical Equipment docking station does not function, ensure AC power is on. If the fan still does not work, replace the fan. If the issue persists, replace the Docking Station System Board.
What to do if the Masimo SET Medical Equipment portable will not turn off?
If your Masimo SET Medical Equipment portable unit will not turn off, try replacing the Portable System Board. If that doesn't work, adjust or replace the Keypad.
What to do if the Masimo SET Radical-7 Medical Equipment battery LED is not illuminated?
If the battery LED is not illuminated on your Masimo SET Medical Equipment, it may indicate that there is no fault and the battery is fully charged. Otherwise, check the 12VDC power. If the problem persists, replace the Docking Station System Board.
What to do if the Masimo SET Radical-7 Medical Equipment display does not rotate automatically?
If the display on your Masimo SET Medical Equipment does not rotate automatically, ensure the docking station is powered up. Also, ensure the Power Save feature is not enabled. If problems persist, replace the Docking Station System Board.
What to do if the Masimo SET Medical Equipment portable will not power up when undocked?
If your Masimo SET Medical Equipment portable unit will not power up when undocked, check the NiMH Battery charge. If charging is not successful, replace the battery. If the problem continues, replace the Portable System Board.
What to do if the Masimo SET Medical Equipment battery LED is flashing?
If the battery LED is flashing on your Masimo SET Medical Equipment, first ensure that Service Mode – Deep Discharge is not enabled. If it is not enabled, allow the NiMH Battery to cool down. Next, verify the fan operation. If the issue persists, replace the NiMH Battery or replace the Docking Station System Board.
This section describes the purpose and scope of the service manual for the Radical-7 Pulse CO-Oximeter.
Explains the meaning of warning, caution, and note labels used throughout the manual to ensure user safety and device integrity.
This chapter covers testing, cleaning, battery, and fuse replacement procedures for the Radical-7 pulse oximeter.
Provides detailed instructions for cleaning the display panel and outer surfaces of the Radical-7 oximeter.
Introduces the battery types for the Radical-7 Handheld and Docking Station and the initial charging requirements.
Details the procedure for charging the handheld and docking station batteries, including LED indicators and charging times.
Step-by-step guide on how to safely remove and replace the battery in the Radical-7 Handheld unit.
Instructions for replacing the battery within the Radical-7 Docking Station, including necessary precautions.
Provides instructions on how to safely replace fuses in the Radical-7 unit, including fuse specifications and precautions.
Explains the Radical-7's software configuration, board independence, and compatibility requirements for upgrades.
Detailed steps for downloading and installing software updates onto the Radical-7 Handheld and Docking Station systems.
Outlines the procedures for testing the Radical-7 pulse oximeter's performance after repairs or during routine maintenance.
Describes the steps to verify the Power-On Self-Test functionality, including LED indicators and audible signals.
Details the process for verifying that each soft key button on the Radical-7 acknowledges presses with beeps or display changes.
Instructions for testing the High and Low Saturation and Pulse Rate alarm limits by adjusting parameters and verifying display.
Procedure to test and adjust the display contrast settings on monochrome Radical-7 units.
Guides the user on using a Masimo SET Tester to verify SpO2 and pulse rate measurements and alarm functions.
Details the procedure for performing a functional test of the %SpCO measurement on the Radical-7.
Details the procedure for performing a functional test of the %SpMET measurement on the Radical-7.
Describes how to perform a functional test for the PVI feature, noting that values fluctuate.
Provides steps to test the Nurse Call functionality by measuring resistance under different alarm conditions.
Instructions for testing the Analog Output signals for SpO2 and Pulse Rate using a multimeter.
Details how to validate the serial port communication using a PC or printer and specifies communication parameters.
Procedure to verify the charging status and functionality of both the handheld and docking station batteries.
Crucial safety warnings and precautions to be followed before disassembling or repairing the Radical-7 unit.
General guidelines for examining the unit, noting serial numbers, software versions, and checking warranty status before repair.
Comprehensive troubleshooting guide with symptoms, causes, and corrective actions for various device failures.
Masimo's policy regarding warranty repair and service, emphasizing the need for authorized personnel.
Detailed steps for cleaning, decontaminating, packaging, and shipping the unit for service or return.
General| Technology | Masimo SET |
|---|---|
| Display | Color Touchscreen |
| SpO2 Range | 0-100% |
| Pulse Rate Range | 25-240 bpm |
| Perfusion Index (PI) Range | 0.02-20% |
| Pleth Variability Index (PVI) Range | 0-100% |
| HbCO Range | 0-40% |
| SpHb Range | 0-25 g/dL |
| SpCO Range | 0-40% |
| ORI Range | 0-100% |
| Pulse Rate Accuracy | ±3 bpm |
| Battery Life | Up to 4 hours |
| SpO2 Accuracy | ±2% (70-100%) |
| Connectivity | Wi-Fi |
| Power Supply | 100-240 VAC, 50/60 Hz |
| Operating Temperature | 5°C to 40°C |
| Humidity Range | 10-95% (non-condensing) |
| Alarms | Audible and visual alarms |
| Measurement Parameters | SpO2, Pulse Rate, PI, PVI, SpHb, SpCO, SpMet, ORI |
| Storage Temperature | -20°C to 60°C |
