Masimo SET Rainbow SET Rad-57 - Direct Connect and Reusable Sensors

Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
8-3
8
Rainbow Direct Connect Sensors
SpO
2
and SpMet and pulse rate accuracy for the Rainbow sensors is specified in the following table.
Rainbow Direct Connect sensors connect to the instrument directly.
SENSOR
Weight
Range
Saturation Accuracy Pulse Rate Accuracy
Low Perfusion
Accuracy
SpMet
Accuracy
No Motion Motion No Motion Motion Saturation Pulse Rate No Motion
DC-3
DC-12
> 30 kg
60 - 80 ± 3%
70 -100 ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 1%
DCP-3
DCP-12
10 - 50 kg
60 - 80 ± 3%
70 -100 ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 1%
Rainbow Reusable Sensors
SpO
2
, SpCO, SpMet and pulse rate accuracy for the Rainbow sensors is specified in the following
table.
Rainbow reusable sensors must be used in conjunction with Rainbow RC cables.
Sensor
Weight
Range
Saturation Accuracy Pulse Rate Accuracy
Low Perfusion
Accuracy
SpCO
Accuracy
SpMet
Accuracy
No Motion Motion No Motion Motion Saturation
Pulse
Rate
No Motion No Motion
DCI > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3% ± 1%
DCIP 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3% ± 1%
Rainbow Resposable™ Pulse CO-Oximeter Sensor System
SpO
2
, SpMet, and pulse rate accuracy for the Rainbow Resposable two piece sensor system is
specified in the following table.
Sensor
Application Site Weight Range
Saturation
Accuracy
Pulse Rate
Accuracy
Low Perfusion Accuracy SpMet Accuracy
Saturation Pulse Rate
R2-25a
R2-25r
Middle or ring
finger
> 30 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3 bpm ± 2% ± 3 bpm ± 1%
R2-20a
R2-20r
Middle or ring
finger
10 - 50 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3 bpm ± 2% ± 3 bpm ± 1%
Sensors and Patient Cables
