Masimo SET Rainbow SET Rad-57 - Masimo SpO2 and LNOP Sensors

8-4
Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
8
Masimo SpO
2
Sensors
The Rad-57 may also use standard Masimo LNOP, LNOPv and LNCS SpO
2
sensors, when used with
Red PC and LNCS Cables respectively. This will allow the Rad-57 to work as a Masimo SET pulse
oximeter without the carboxyhemoglobin or methemoglobin measurement.
Select the appropriate patient cable to attach the LNOP, LNOPv or LNCS sensor to the instrument.
Red Reusable Sensors
SpO
2
and pulse rate accuracy for the Red sensors is specified in the following table.
Sensor
Weight Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy
Range No Motion Motion No Motion Motion Saturation Pulse Rate
Red DCI > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
Red DCIP 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP
®
Reusable Sensors
LNOP sensors must be used in conjunction with Red PC cables.
Sensor
Weight Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy
Range No Motion Motion No Motion Motion Saturation Pulse Rate
LNOP DCI > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP DCIP 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP YI > 1 kg ± 2% ± 3% ± 3 bpm ± 5 bpm N/A N/A
LNOP TC-I > 30 kg ± 3.5% N/A ± 3 bpm N/A ± 3.5% ± 3 bpm
LNOP DC-195 > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP TF-I > 30 kg ± 2% N/A ± 3 bpm N/A ± 2% ± 3 bpm
NOTE: The LNOP TF-I and TC-I sensors were not validated under motion conditions.
LNOP
®
Adhesive Sensors
LNOP sensors must be used in conjunction with Red PC cables.
Sensor
Weight Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy
Range No Motion Motion No Motion Motion Saturation Pulse Rate
LNOP Adt > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP Adtx > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP Pdt 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP Pdtx 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP Neo-L
< 3 kg ± 3% ± 3% ± 3 bpm ± 5 bpm ± 3% ± 3 bpm
> 40 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
LNOP NeoPt-L < 1 kg ± 3% ± 3% ± 3 bpm ± 5 bpm ± 3% ± 3 bpm
LNOP Inf-L 3 - 20 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
Sensors and Patient Cables
