Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
8-5
8
LNOP
®
Specialty Sensors
LNOP sensors must be used in conjunction with Red PC cables.
Sensor
Weight Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy
Range No Motion Motion No Motion Motion Saturation Pulse Rate
LNOP Blue 2.5 - 30 kg
60 - 80% ± 4% N/A ± 3 bpm N/A ± 3% ± 3 bpm
70 - 100% ± 3.3% N/A ± 3 bpm N/A ± 3% ± 3 bpm
80 - 100% ± 3% N/A ± 3 bpm N/A ± 3% ± 3 bpm
LNOP Trauma
> 30 kg
± 2% ± 3% ± 3 bpm ± 5 bpm
N/A N/A
LNOP
Newborn Neo
< 3 kg ± 3% ± 3% ± 3 bpm ± 5 bpm ± 3% ± 3 bpm
LNOP
Newborn Inf
3 - 20 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS
™
/LNCS
®
Reusable Sensors
M-LNCS sensors must be used in conjuction with Rainbow patient cable series. LNCS reusable sensors
must be used in conjunction with Red LNC cables.
M-LNCS/LNCS
DCI
> 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS/LNCS
DCIP
10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS/LNCS
TC-I
> 30 kg ± 3.5% N/A ± 3 bpm N/A ± 3.5% ± 3 bpm
M-LNCS/LNCS
TF-I
> 30 kg ± 2% N/A ± 3 bpm N/A ± 2% ± 3 bpm
M-LNCS/LNCS YI > 1 kg ± 2% ± 3% ± 3 bpm ± 5 bpm N/A N/A
NOTE: The M-LNCS and LNCS TF-I and TC-I sensors were not validated under motion conditions.
M-LNCS
™
/LNCS
®
Adhesive Sensors
M-LNCS sensors must be used in conjuction with Rainbow patient cable series.
LNCS sensors must be used in conjunction with Red LNC cables.
SENSOR
Weight
Range
Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy
No
Motion
Motion No Motion Motion Saturation Pulse Rate
M-LNCS/LNCSAdtx
M-LNCS/LNCSAdtx-3
> 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS/LNCS Pdtx
M-LNCS/LNCS Pdtx-3
10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS/LNCS Inf-L
M-LNCS/LNCS Inf
M-LNCS/LNCS Inf-3
3 - 20 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS/LNCS Neo-L
M-LNCS/LNCS Neo
M-LNCS/LNCS Neo-3
< 3 kg ± 3% ± 3% ± 3 bpm ± 5 bpm ± 3% ± 3 bpm
> 40 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
M-LNCS/LNCS NeoPt
M-LNCS/LNCSNeoPt-L
M-LNCS/LNCS NeoPt-3
< 1 kg ± 3% ± 3% ± 3 bpm ± 5 bpm ± 3% ± 3 bpm
M-LNCS/LNCS
NeoPt-500
< 1 kg ± 3% ± 3% ± 3 bpm ± 5 bpm ± 3% ± 3 bpm
Sensors and Patient Cables
