Masimo NomoLine ISA CO2 User Manual

www.masimo.com 15 Masimo
Chapter 2: Setting Up
This chapter contains information about setting up NomoLine ISA CO2 before use.
System Setup
During setup, refer to the host device operator's manual or user's guide, in addition to the
following procedure.
1. Remove the temporary plug from the NomoLine Capnography input connector.
2. Securely mount the NomoLine ISA CO2.
Note: A bracket designed to mount NomoLine ISA CO2 is available, visit
www.masimo.com.
3. Connect the gas sample exhaust port on the rear of NomoLine ISA CO2 to a
scavenging system if intended to be used in combination with N2O and/or
anesthetic agents.
4. Connect the NomoLine ISA CO2 cable to the host device connection port.
5. Connect a NomoLine sampling line to the NomoLine ISA CO2 input connector. See
Front View on page 13.
6. Check that host device is powered up and correctly configured.
7. Check that the LEGI indicator shows a steady green light, indicating that
NomoLine ISA CO2 is ready for use. See LEGI Indicator on page 17.
Note: Without a sampling line connected, the LEGI Indicator does not illuminate.
8. Attach a NomoLine sampling line to the patient for monitoring. Refer to the
NomoLine sampling line Directions for Use.
9. Following connection of the NomoLine sampling line, check that CO
2
values
appear on the host device screen. See Capnography Display on page 17.
