O3 Regional Oximeter Chapter 4: Operation
www.masimo.com 32 Masimo
Body Sensor Sites
Select Body in the upper left corner of the screen to switch to the Body Sensor Sites locations
display.
Ref
Description
1 Current location of sensor 1 and sensor 2 (Head).
2 Choose either the Sensor 1 or Sensor 2 button to select the sensor and change sensor
site location. Only the selected sensor can be changed.
3 Touch the new desired sensor site location in the image. The sensor site can be on the
left, or right side of the body.
4
The new sensor site location will be displayed. Select OK to confirm the change. Repeat
this process for the corresponding sensor as necessary. Press the Home button to return
to the Main Screen.
