O3 Regional Oximeter Chapter 4: Operation
www.masimo.com 31 Masimo
Head Patient View
Head is the default view when Site Selection is displayed.
Ref
Description
1 Choose either sensor 1 then sensor 2 to change sensor site location. Only the selected
sensor location can be changed.
Note that 1 is defaulted to Forehead Left and 2 is defaulted to Forehead Right.
2 Touch the new desired sensor site location in the image. The sensor site can be on the
left, or right side of the body.
3 The new sensor site location will be displayed. Select OK to confirm the change. Repeat
this process for the corresponding sensor as necessary. Press the Home button to return
to the Main Screen.
