Waveform and Trend Views
The following section contain information about trends and waveforms
available from the
Trend Field
on the
Display View
screen. The following
are examples of some of the views that are available.
Pleth + Sig IQ + Acoustic View
Shows the parameter values on the top of the screen. The waveform is
located below the parameter values. The
Small Parameter
view is located
along the bottom of the screen. This view contains the Pleth waveform,
signal quality indications, and acoustic waveform.
