Root with Pathway Pathway
www.masimo.com 23 Masimo
• After 96 hours the Time Scrub Button displays >96:00:00.
6. To stop the Pathway procedure, select the Stop button at the bottom of the screen.
Confirm by selecting the Stop button again in the confirmation window. The
screen returns to the Pathway Main Screen. To continue with the Pathway
procedure, select Cancel in the confirmation window.
Trend
The SpO
2
and PR trends display on the Pathway screen.
Note: Panning left/right on the screen is disabled during the first 11 minutes of monitoring.
The SpO
2
trend changes colors depending on location in relation to the glide path (target
range). See SpO2 Target Range on page 14. SpO
2
trend colors include:
• Black - before and after the glide path.
• Green - within the glide path.
• Red - above or below the glide path.
The PR trend changes colors depending on relation to the PR Threshold Settings. See PR
Threshold on page 15. PR trend colors include:
