Master MSPG-8000 - Page 11

Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 11
7) “MG-HDMI2.1/ARC-1” : HDMI 2.1 8K/60Hz outputs
① Output signal: HDMI 2.1Ver x 1port
② Output Spec.: 100MHz~1.2GHz / 8Kx4K@60Hz
③ Supports to HDCP 1.4 and 2.3
④ D/L : Slot upgrade port
8) “MG-USB TYPE-C” : DISPLAYPORT 1.2
① Output signal: DISPLAYPORT 1.2Ver
② Max resolution: 4Kx2K@60Hz
③ Supports to HDCP 1.2 and 2.2
④ D/L: slot upgrade port
⑤ POWER: The POWER port that can be connected to a separate MSPW-100W to power the display
equipment.
