4.2.3 Timing edit list
Common Option
MODE
NO.
LIST
DESCRIPTION
SETTING
C
O
M
M
O
N
O
P
T
I
O
N
1
Mode
Video mode setting
0~3
ANALOG mode setting
ANALOG=0
DIGITAL mode setting
DIGITAL=1
COMPONENT mode setting
COMP=2
CVBS mode setting
CVBS=3
2
Dot_Frequency(MHz)
Input the Dot Frequency as MHz.
Number
3
HS_Frequency(KHz)
Input the Horizontal Frequency as KHz.
Number
4
VS_Frequency (Hz)
Input the Vertical Frequency as Hz.
Number
5
H_Total (Dot/uS)
Input the data as Dot or Time for whole pixels of marking
Horizontal 1 line.
Number
6
H_Display (Dot/uS)
Input the data as Dot or Time for available pixels of marking
Horizontal 1 line.
Number
7
Hfront_Porch (Dot/uS)
Input the data as Dot or Time for one of the line
that is not display from the right side of screen.
Number
8
HS_Width (Dot/uS)
Input the data as Dot or Time for Horizontal returning section.
Number
9
V_Total (Lim/mS)
Input the data as line or time for whole line of one frame.
Number
10
V_Display (Lim/mS)
All of Vertical display line frame except vertical front porch
and back porch.
Number
11
Vfront_Porch(Lim/mS)
No video section of one frame at the bottom.
Number
12
VS_Width (Lim/mS)
Vertical recurrence period.
Number
13
HS_Polarity
Select the Polarity of Horizontal sync
0 or 1
Horizontal sync setting to negative “-“
Negative(-)=0
Horizontal sync setting to positive “+“
Positive(+)=1
14
VS_Polarity
Select the Polarity of Vertical sync
0 or 1
Vertical sync setting to negative “-“
Negative(-)=0
Vertical sync setting to positive “+“
Positive(+)=1
15
Interlace
Interlace setting
0~2
Default / Interlace None setting(No=0)
No=0
Interlace setting with Video Signal(S&V=1)
S&V=1
Interlace setting without Video Signal(S=2)
S=2
16
Resolution Display
Current resolution display on the monitor or not.
0 or 1
Default / Current resolution none display.
No = 0
Current resolution display on the monitor at the center below.
Yes = 1
