Master MSPG-8000 - Page 50

Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 50
⑤ Color Bar pattern No.508 edit value and result.
Ref.no 508
Color bar pattern
1.Color Bar H/V divide
8
4
4
8
2.Gray Size
0
30
50
50
3.Gray Step by one color
2
2
2
2
4.Gray 1 level
255
255
255
255
5.Color 1 R Level
255
255
0
0
6.Color 1 G Level
255
255
0
0
7.Color 1 B Level
255
255
0
0
8.Color 2 R Level
255
255
255
0
9.Color 2 G Level
255
255
255
0
10.Color 2 B Level
0
0
0
0
11.Color 3 R Level
0
0
0
0
12.Color 3 G Level
255
255
255
0
13.Color 3 B Level
255
255
255
0
14.Color 4 R Level
0
0
0
0
15.Color 4 G Level
255
255
255
0
16.Color 4 B Level
0
0
0
0
17.Color 5 R Level
255
255
255
255
18.Color 5 G Level
0
0
0
255
19.Color 5 B Level
255
255
255
255
20.Color 6 R Level
255
255
255
255
21.Color 6 G Level
0
0
0
255
22.Color 6 B Level
0
0
0
255
23.Color 7 R Level
255
255
255
255
24.Color 7 G Level
0
0
0
255
25.Color 7 B Level
0
0
0
255
26.Color 8 R Level
0
0
0
255
27.Color 8 G Level
0
0
0
255
28.Color 8 B Level
0
0
0
255
