30
ChargeMaster Plus 12/35-3, 12/50-3, 24/20-3, 24/30-3 – User and Installation Manual
7.3 Dimensions
Dimensions in mm [inches] of the ChargeMaster Plus 12/35-3, 12/50-3, 24/20-3, 24/30-3.
7.4 Characteristics
Output power (%)
AC voltage (V)
Figure 8: Output power versus input voltage
