ChargeMaster Plus 12/35-3, 12/50-3, 24/20-3, 24/30-3 – User and Installation Manual
WARNING!
All electrical systems (AC and DC)
must be disconnected from any
power source during the entire
installation!
CAUTION!
Too-thin cables and/or loose
connections can cause dangerous
overheating of the cables and/or
terminals. Therefore, tighten all
connections well, in order to limit
transition resistance as far as
possible. Use cables of the correct
size.
CAUTION!
Short circuiting or reversing polarity
may lead to serious damage to the
batteries, the ChargeMaster Plus, the
cabling and/or the terminal
connections. Fuses between the
batteries and the ChargeMaster Plus
cannot prevent damage caused by
reversed polarity. The damage as a
result of reverse polarity is
detectable by the service depart-
ment and is not covered by the
warranty.
3.8 Installation step-by-step
Open the connection
compartment by loosening the two
Fix the enclosure to the wall by
fastening two screws at the lower side
of the ChargeMaster Plus as well.
