13. MASTERBUS ON THE MLI ULTRA
A display like the SmartRemote or EasyView 5, can be used to monitor the MLI Ultra. Advanced
configuration can be done in MasterAdjust, from a Windows laptop or notebook connected to the
MLI Ultra via a Mastervolt USB Interface. The following tables list the parameters as shown in
MasterAdjust.
Monitoring
Menu
Description
Battery/Cluster
State of charge
Battery state of charge in %
Time remaining
Time of battery use left at the actual load in hh:mm:ss
Voltage
Battery voltage measured by the cell management system
Current
Current measured by the cell management system
Positive value: charging, negative value: discharging
Temperature
Internal temperature of the battery in °C
Relay
Relay close
Button to close the safety relay (connect).
Relay open
Button to open the safety relay (disconnect).
Relay state
State of the relay: open / close / not connected
Remote opened
Indication if the relay was opened by another connected MLI Ultra unit
Note: you need to login as installer to see all following parameters.
Installer
DIPswitch state
For CZone, the DIP switches of the MLI Ultra must match the unique
address used in the CZone network
Battery safety
Indication of the occurrence of a Battery Safety event; see section
Battery safety event on page 22
Stop charge
Indication of the occurrence of a Stop charge event; see section Stop
Charge event on page 21
Voltage
Cell 1 … 8
Voltage of the individual cells
Balancer
Balancer 1…8 act.
Indication of active balancing of the individual cells
Temperature
Temperature 1, 2-3,
4-5, 6-7, 8
Temperature of the cells
