MLI Ultra 12/2750, 12/5500, 24/5500 – User and Installation Manual
Protection
The MLI Ultra is equipped with a Battery Management System (BMS). The BMS:
- balances the voltages between the cells;
- protects each cell from undercharging and overcharging;
- prevents too deep battery discharges;
- monitors the temperature of battery cells;
- communicates with Mastervolt charge devices over MasterBus or CZone;
- sends out warnings and alarms (to a display like the SmartRemote or EasyView 5 e.g.).
These protection and alarm features can be programmed as MasterBus events/CZone circuits,
that display warnings or intervene on the electrical system.
Identification label
The identification label is located on the top side of the MLI Ultra
5500 and on the back side of the MLI Ultra 2750. Technical
information required for service and maintenance (part number,
serial number and revision code) can be derived from the
identification label.
CAUTION!
Never remove the identification label.
This will void the warranty.
6. INSTALLATION
For information on creating systems with multiple units in parallel or series, also see chapter 15.
Unpacking
The delivery consists of the following parts:
- MLI Ultra battery
- MasterBus terminator
- Safety relay connector + jumper wire
- Drop cable CZone/MB (1m)
- 2x M8 bolt + washer + spring washer
- The user and installation manual
- Mounting straps
Check the battery
Check the battery for possible damage and the open clamp voltage with a suitable voltage meter.
Never use a damaged battery or a battery with an open clamp
voltage that is out of range. If in doubt, contact your Mastervolt
supplier. Optionally save the original packaging for future
transport of the battery.
Choosing a location to install
- Install the MLI Ultra in a well-ventilated room protected against rain, snow, spray, vapor, bilge,
moisture and dust.
Allowed open clamp voltage
Model
Minimum
Maximum
12V
12.0V
14.6V
24V
24.0V
29.2V
