MLI Ultra 12/2750, 12/5500, 24/5500 – User and Installation Manual
33
System parts
A
MLI Ultra battery
B
Battery fuse in positive battery cable
C
Safety relay
D
MasterBus/CZone connection (see section Network wiring on pages 16 and 24)
E
MasterBus compatible charger
F
Fuse to protect the charger cable
G
Negative busbar
H
Positive busbar
Relay wires
Connect to
Description
(1) Red wire
Relay Control (RC) positive
(2) Brown wire
Close relay pulse
(3) Orange wire
Open relay pulse
(4) Black wire
RC minus
(5) Yellow wire
FeedBack signal relay
(8) Jumper wire (comes
with MLI Ultra)
to
Relays connector detect, connect to RC minus
