MLI Ultra 12/2750, 12/5500, 24/5500 ā User and Installation Manual
6. Click the Confirm topology button.
Notice the status of the cluster topology. It can be:
- Needs approval: the topology was not confirmed;
- Not activated: the topology still requires activation;
- Too many devices/Double device/Incomplete/Missing self: the
proposed topology is not possible or other units need to be
selected.
After confirmation, the cluster topology is defined and fields to
select the other units will appear.
7. In the S01 field, from the drop-down list, select the serial number
of the master battery. This battery will be the Cluster Master and
will show the Cluster state.
8. In the following fields, select the other clustered batteries.
9. Click the Activate button.
Now, each battery will show its individual data in the monitoring
tab while the Master battery will show both the individual data and
the data of the cluster.
Activation will fail if the battery is already in another cluster.
To access the individual batteries, unfold the cluster (i.e. click the plus sign) in the left panel of
MasterAdjust.
To identify the Master, go to the configuration page of one of the (other) batteries.
To remove a device from a cluster, click the Detach button.
To breakdown a cluster, in the configuration of the Master: set the cluster to 1 (series) by 1 (parallel)
and click the Confirm topology button.
