Matrix Impact2 - Display

PIPETTOR OVERVIEW
12
B.3 Display
The pipettor display is a dynamic LCD screen. It displays the
current operation, volume prompt (if you are entering a program),
pipetting volume, low battery indicator (appears if battery charge is
low), beep tone symbol (if the beep tone is on), pipetting speed,
and program number (IMPACT
2
only).
Pipetting Operations
Volume Prompt Pipetting Volume
Low Battery Indicator
Beep Tone Speed Setting Purge Prompt
Figure B.3a: IMPACT Display
Pipetting Operations
Volume Prompt
Pipetting Volume
Low Battery Indicator
Speed Setting Purge Prompt
Beep Tone
Program No.
Figure B.3b: IMPACT
2
Display
