Autoclaving
3
PIPETTOR DISASSEMBLY
NOTE: Follow standard laboratory practices for using or servicing
equipment that is exposed to biohazardous material.
1. Remove the color ring by gently prying loose one of the edges
near the handle trigger.
2. Use a Phillips screwdriver to remove all three housing screws.
3. Carefully remove the plastic cover housing and observe the
layout of the internal parts.
Cover Housing
Figure 1: Removing Cover Housing
