NVRX LED And Buzzer State
The NVRX variants has a set of LEDs and Buzzer for indication of events on the SATATYA NVRX series. It has
been explained in the table below.
State Description Status LED Cadence Power LED Buzzer (System)
Supply is connected but
application is not yet initialized.
OFF
Green
Steady
N.A.
On Application Initialization
Red
1000 - ON and 1000 – OFF
3000 – ON
System in normal state
(Connected to network).
Green
500 - ON and 500 – OFF
N.A.
Storage Incomplete Volume.
Red
1000 ON–5000 OFF
1000 - ON and 5000 –
OFF
Storage Full Alert.
Red
2000-ON–2000 OFF
N.A.
Storage Full.
Red
1000 ON–3000 OFF
N.A.
Formatting Disk.
Red
1000 ON–1000 OFF
N.A.
Firmware upgrade in process.
Orange
(ON till firmware upgrade
process completes)
N.A.
Firmware upgrade failed.
Red
1000 ON–1000 OFF
1000 - ON and 1000 –
OFF
Recording failed for 1 or more
enabled cameras (Not all)
Orange
(500 – ON and 500 – OFF)
ON till recording of all enabled
cameras gets started
N.A.
Recording failed for all enabled
cameras
Red
(Steady Light till recording of
any one enabled camera gets
started)
N.A.
Trigger from Event
Green
500 - ON and 500 – OFF
3000 - ON and 1000 –
OFF
Backup Device full
Green
500 - ON and 500 – OFF
1000 - ON and 2000 –
OFF
No Backup Device
Green
500 - ON and 500 – OFF
1000 - ON and 3000 –
OFF
Temperature reached at 100
degree
Red
500 - ON and 500 – OFF
Green
Steady
500 – ON and 5000 –
OFF
Temperature reached at 105
degree
System shuts down N.A.
After crossing 100 degrees,
Temperature comes back to less
than 100 degree
System automatically comes
in normal stage and cadence
stops
N.A.
