Matrix SATATYA NVR0801X System Manual

16 Matrix SATATYA Devices Manual
NVR Front Panel USB Connections
USB 1-4: Defined for Front Panel.
USB 5-6: Defined for Rear Panel (Explained in Rear Panel section).
BACKUP
LED
Backup.
LED does not
illuminate if backup
devices is
disconnected
Yes No Yes No No
POWER
Button
Power Button to be
pressed to shutdown
or restart the device.
No No Yes No No
POWER
LED
The Power LED to
indicate the status to
indicate the NVR
device. LED does not
illuminate if the NVR is
disconnected from the
network.
Yes Yes Yes Yes No
Remote
Controller
Sensor
To operate the IR
Remote Control.
Yes Yes Yes Yes No
Reset
Press and hold down
the reset button for
atleast 4 seconds to
default
the following
parameters.
• LAN Settings
• User Settings.
• General Settings
• Resolution Settings
Yes No No No No
Interface NVR8S NVR16S NVR24P NVR16H NVR64S/P
USB 1
Yes (Mouse,
Dongle)
No
Yes (Schedule
Backup)
Yes (Mouse) No
USB 2 Yes (Backup) No
Yes (Manual
Backup)
Yes (Manual
Backup)
No
USB 3 No No Yes No No
USB 4 No No Yes No No
Interface Function NVR8S NVR16S NVR24P NVR16H NVR64S/P
