Matrix SATATYA NVR0801X System Manual

Matrix SATATYA Devices Manual 229
Motion Detection:
In Local Client
Check the Motion Detection check box to enable the event. Click on the Set button to define the Motion Zone for
the selected camera. The 1x1 monitoring view of the camera appears with the overlying grid as shown.
Right click on this window and select the Set Area option. Select the square zones in the grid, by left clicking the
mouse to define the motion detection area. The user can also drag and drop the mouse cursor to define the area.
To save the selected motion zone, right click on the monitoring window again and select Exit. The Maintain
Changes window appears. Select Yes to save the changes. The system returns to the Detection Settings window.
To set the sensitivity, right click on the monitoring window and select the Sensitivity option.
In order to clear the defined motion detection area, right click on the monitoring window and select the Clear All
option.
Select the channels which will start video recording in the event of a motion being detected in the motion zone of
the selected camera or channel by checking the boxes against the respective channels.
Click on Save once done.

Matrix SATATYA NVR0801X Specifications

General

Brand	Matrix
Model	SATATYA NVR0801X
Category	DVR
Language	English
