Matrix SATATYA Devices Manual 265
Broadband Settings
The Matrix SATATYA HVR supports mobile broadband as one of the modes of communication for remote access.
The appropriate broadband USB dongle has to be inserted into the USB port available on the device for broadband
communication.
In order to configure the parameters for mobile broadband communication, Select Network Settings and click on
Broadband option. The Broadband Settings page appears as shown below:
The following broadband network parameters can be configured from this page:
• Active Profile: In the event of having multiple broadband options, select the one currently connected to
the USB port of the HVR by scrolling the arrows. The options are Airtel, BSNL, Vodafone, TATA Photon+
and Reliance.
• Profile Number: Each profile can be assigned a unique profile number. Select a number for this profile by
scrolling the arrows.
• Profile Name: Specify a user friendly profile name for the connection.
• Dial Number - Specify the dial number as provided by the service provider which needs to be dialled to get
connectivity. For example the dial number for Airtel is *99#.
• User Name - Specify the user name for the authentication.
• Password - Specify the password for the authentication.
• Service - Select the type of service from the options of GSM and CDMA.
• APN - Specify the access point name which is a URL specific to the service provider. It is required only if
service selected is GSM.
Profile Number Profile Name Dial Number Service APN
1 Airtel *99# GSM airtelgprs.com
2 BSNL *99***1# GSM Bsnl.net
3 Vodafone *99# GSM Portalnmms
4 TATA Photon+ *777 CDMA NA
