RAID Creation in NVRX series variants
As explained above, in SATATYA NVRX Series variants RAID level can be configured based on the number of
SATA interfaces available in the particular variant. The table below indicates the HDD modes/RAID levels and the
paring of drives in each NVRX series variant.
While RAID creation, if the pairing of drives is not done as defined in the table below, then the message
displaying incorrect HDD combination will appear. So it is recommended to refer this table prior RAID
creation.
NVRX Series Variants
Number of SATA
Interfaces Available
HDD Modes Supported
Pairing of Drives based on
connected HDD
NVR0801X 1 Single Disk Volume 1
NVR1601X 1 Single Disk Volume 1
NVR1602X/NVR3202X 2
Single Disk Volume 1
RAID 0 1-2
RAID 1 1-2
NVR3204X/NVR6404X 4
Single Disk Volume 1
RAID 0 1-2 and 3-4
RAID 1 1-2 and 3-4
RAID 5 Volume A 1-2-3 and 1-2-3-4
RAID 10 Volume A 1-2-3-4
NVR6408X 8
Single Disk Volume 1
RAID 0 1-2, 3-4, 5-6 and 7-8
RAID 1 1-2, 3-4, 5-6 and 7-8
RAID 5 Volume A
1-2-3, 1-2-3-4, 5-6-7 or 5-6-
7-8
RAID 10 Volume A 1-2-3-4 and 5-6-7-8
