Alarm Inputs 2 Sensor inputs 2 Sensor inputs 2 Sensor inputs 2 Sensor inputs
Alarm outputs
1 Alarm output 1 Alarm output 1 Alarm output 1 Alarm output
General
Power Supply 12 VDC, 5 A 12 VDC, 5 A 100-240 VAC, 50-60Hz 100-240 VAC, 50-60Hz
RAID Single Disk RAID 0, RAID 1,
Single Disk
RAID 0, RAID 1, RAID
5, RAID 10, Single
Disk
RAID 0, RAID 1, RAID
5, RAID 10, Single
Disk
Power
Consumption
(Typical)
20W 30W 50W 65W
Operating
temperatures
0°C to +50°C
(32°F to 122°F)
0°C to +50°C
(32°F to 122°F)
0°C to +50°C
(32°F to 122°F)
0°C to +50°C
(32°F to 122°F)
Humidity Range
5% to 95% RH
Non-Condensing
5% to 95% RH
Non-Condensing
5% to 95% RH
Non-Condensing
5% to 95% RH
Non-Condensing
Dimensions (W x
H x D)
(in mm)
320mm(without
clamp) X 45.85mm
X 195.5mm
425.5mm (without
clamp) X 54.6mm X
196mm
442mm (without
clamp) X 105.75mm X
240.45mm
442mm (without
clamp) X 105.75mm X
355.45mm
Weight (without
HDD)
1.2 Kgs 1.5 Kgs 3.7 Kgs 5.5 Kgs
Note: Specifications are subject to change without notice.
Functions
SATATYA
NVR8S
SATATYA
NVR16S
SATATYA
NVR24P
SATATYA
NVR16H
SATATYA
NVR64P/S
Compression
Algorithm
H.264,MPEG-
4,M-JPEG (as
supported by
the connected
camera)
H.264/MPEG4/
Motion JPEG (as
supported by the
connected
camera)
H.264,MPEG-
4,M-JPEG (as
supported by the
connected
camera)
H.264/MPEG4/
Motion JPEG (as
supported by the
connected
camera)
H.264,MPEG-
4,M-JPEG (as
supported by the
connected
camera)
Audio
Compression
G.711 G.711 G.711 G.711 G.711
Snapshot
Format
JPEG JPEG JPEG JPEG JPEG
Video
VGA Video
Output
One 15 pin
D(5+5+5)
connector
One 15 pin
D(5+5+5)
connector
One 15 pin
D(5+5+5)
connector
One 15 pin
D(5+5+5)
connector
One 15 pin
D(5+5+5)
connector
Functions
NVR0801X/
NVR1601X
NVR1602X/
NVR3202X
NVR3204X/
NVR6404X
NVR6408X

Matrix SATATYA NVR0801X Specifications

General

Brand	Matrix
Model	SATATYA NVR0801X
Category	DVR
Language	English
