Status LED Cadence in NVR64S/P
Channel Green
Steady Camera is connected to the
respective channel
State Description Status LED Cadence Power LED Buzzer (System)
Supply is connected but
application is not yet initialized.
OFF
Green
Steady
N.A.
On Application Initialization
Red
1000 - ON and 1000 – OFF
3000 – ON
System in normal state
(Connected to network).
Green
3000 - ON and 1000 – OFF
N.A.
Storage Incomplete Volume.
Orange
1000 ON and 5000 OFF
1000 - ON and 5000 –
OFF
Storage Full Alert.
Orange
2000-ON and 2000 OFF
N.A.
Storage Full.
Orange
1000 ON and 3000 OFF
N.A.
Formatting Disk.
Orange
1000 ON and 1000 OFF
(Continue cycle until disk is
formatted)
N.A.
Firmware upgrade in process.
Red
1000 - ON and 2000 – OFF
(Continue Cycle till process
completion)
N.A.
Firmware upgrade failed.
Red
1000 - ON and 1000 – OFF
(30 cycles)
1000 - ON and 1000 –
OFF
Trigger from Event N.A. N.A.
3000 - ON and 1000 –
OFF
Disk Normal
Green
3000 - ON and 1000 – OFF
Green
Steady
N.A.
Disk Error
Green
3000 - ON and 1000 – OFF
N.A.
No Disk
Green
3000 - ON and 1000 – OFF
N.A.
LED Function Color Cadence Description

Matrix SATATYA NVR0801X Specifications

General

Brand	Matrix
Model	SATATYA NVR0801X
Category	DVR
Language	English
