7. Reinstall locking brackets
on both cylinders (FIG.
51- 1). Bolt each locking
bracket in place.
STEP 11 - ADJUST PLATFORM (IF REQUIRED)
- Continued
9. RAISE platform to position
just below extension plate
(see FIG. 51-2). Refer to
operating instructions in
Operation Manual.
FIG. 51-2
8. Review the WARNING page at
the front of this manual before
continuing this procedure. Stay
clear of moving Liftgate parts.
REINSTALLING LOCKING BRACKETS
FIG. 51-1
LOCKING
BRACKET
CAP NUT
FLAT
WASHER
BOLT
LH CYLINDER
RH
CYLINDER
LOCKING BRACKET
(2 PLACES)
To Next Page
