USER Manual
44
When battery replacement is necessary, the battery level on the LCD display
indicates ‘LOW’ and a ‘LOW’ battery image appears on the upper right part
of the main control display. The battery replacement-indicating light on the
upper part of main body will be yellow, as well.
The battery level display and remaining battery life shown on the right side
of the main control screen is demonstrated in Figure 7.12. Replace the
battery once the display indicates that 0~10% battery life remains.
7.12 Battery level display/remaining battery life
If the device is used for too long after the 'LOW' battery signal began blinking,
the warning message in Figure 7.13 will appear on the LCD display for a few
seconds before the device powers off.
81~100% 56~80% 31~55% 11~30% 0~10%
CHECK
Recharge the battery pack once the LOW battery sign on the
LCD screen is displayed. When changing the battery pack, take
care not to drop it and ensure it is inserted correctly.
