uNPACKING AND VERIFYING COMPONENTS
Copyright © 2017 McCrometer, Inc. All printed material should not be changed or altered without permission of
McCrometer. Any published technical data and instructions are subject to change without notice. Contact your McCrometer
representative for current technical data and instructions.
www.mccrometer.com
3255 WEST STETSON AVENUE • HEMET, CALIFORNIA 92545 USA Printed In the U.S.A.
TEL: 951-652-6811 • 800-220-2279 • FAX: 951-652-3078 Lit. # 30120-48 Rev. 2.4 / 11-5-18
3
The tag on the side of the converter has the Converter Model Number, the Converter Serial Number and the Meter
Serial Number. An example is shown below as Figure 3.
Figure 2. Meter Serial Number Tag
Figure 3. Converter Serial Number Tag
IMPORTANT: Verify the meter serial numbers on both the converter and sensor match. If the Meter Serial
Numbers do not match, contact the factory before continuing with the installation.
i
1.2 Verify Serial Numbers
The FPI Mag ow meter is comprised of two primary components: the sensor and the converter. The converter
and sensor are supplied as a custom calibrated matched system. Verify the system serial numbers on both the
converter and sensor match. This will ensure a properly calibrated system.
The Meter Serial Number is located on the side of the sensor body on a silver label. An example is shown below
as Figure 2.
Converter Model: 880003xxx
Converter SN: E12-34567
Meter Model: FPI 395L
Meter SN: MI12-0448
http://www.mccrometer.com
USC
®
MI12-0448
MANUFACTURED: JANUARY 2013
MAXIMUM WATTAGE: 20W
FOREIGN PATENTS PENDING
U.S. PATENT 8,136,410
3255 W. STETSON AVE., HEMET CA 92545 USA
PH (951) 652-6811 • http://www.mccrometer.com
1.3 Verify Information On Cable Tags
The converter cable has two tags located near where the cable enters
the converter as shown in Figure 4. Verify the following information
is consistent with the specications provided at the time of order:
Figure 4. Cables with CableTags
Tag 1
Meter Serial Number
Pipe I.D. (millimeters)
KA Factor
Tag 2
Pipe I.D. (inches)
Total Sensor Length
Total Cable Length
Cable Tags
Converter Model Number
Converter Serial Number
Meter Serial Number
