Reel Disk from McFarlane Mfg. 24 800-627-8569
WARNING
To prevent serious injury or death from rolling over
or crushing during the setup procedure:
STOP
Stop tractor’s engine.
P
Set parking brake.
Remove ignition key.
Block wheels of unit.
b. Stop the tractor, shut off the engine, set the parking
brake, and remove the ignition key from the tractor.
c. Block the wheels of the unit to prevent unwanted
movement while repositioning the disk gangs.
d. Release the wire retainer clips and remove the
retainer pins.
e. Adjust the disk gang to the desired angle.
The #1 position (5°) is the least aggressive setting
and is typically used with higher speeds and
smaller amounts of residue.
The #2 position is more aggressive at a (7°) angle.
The #3 position is still more aggressive at a (10°)
angle.
