McFarlane 4100 Series - Page 63

800-627-8569 63 Reel Disk from McFarlane Mfg.
Disk Mount and Scrapers for RD-4100 (continued)
Item Part Number Description
1 BHY-1310 1-1/4-7 x 10 BOLT GD 8
2 NY-1307 1-1/4-7 NYLON LOCK NUT
3 BHY-1395 1-1/4-7 x 9-1/2 BOLT GD 8
4
RD-4890 DISK ADJUST CLAMP GD 8
5
QT-1209 SPACER
6
QT-1081 BEARING MOUNT, TRUNNION
7
RD-4950
RD-4951
RD-5043
RD-5044
RD-4952
RD-4953
RD-4954
RD-4955
RD-4956
RD-4957
RD-4896
RD-4913
RD-4922
RD-4926
RD-4904
RD-4910
RD-4958
RD-4959
RD-4960
RD-4961
RD-4962
RD-4963
RD-4964
RD-4965
RD-4966
RD-4967
DISK MOUNT TUBE LT 4112
DISK MOUNT TUBE RT 4112
DISK MOUNT TUBE LT 4114
DISK MOUNT TUBE RT 4114
DISK MOUNT TUBE LT 4116
DISK MOUNT TUBE RT 4116
DISK MOUNT TUBE MAIN LT 4120
DISK MOUNT TUBE MAIN RT 4120
DISK MOUNT TUBE WING LT 4120
DISK MOUNT TUBE WING RT 4120
DISK MOUNT TUBE MAIN LT 4125-4130
DISK MOUNT TUBE MAIN RT 4125-4130
DISK MOUNT TUBE WING LT 4125
DISK MOUNT TUBE WING RT 4125
DISK MOUNT TUBE WING LT 4130
DISK MOUNT TUBE WING RT 4130
DISK MOUNT TUBE MAIN LT 4135
DISK MOUNT TUBE MAIN RT 4135
DISK MOUNT TUBE WING LT 4135
DISK MOUNT TUBE WING RT 4135
DISK MOUNT TUBE MAIN LT 4145
DISK MOUNT TUBE MAIN RT 4145
DISK MOUNT TUBE WING LT 4145
DISK MOUNT TUBE WING RT 4145
DISK MOUNT TUBE WING LT OUTSIDE 4145
DISK MOUNT TUBE WING RT OUTSIDE 4145
8 BHY-7535 3/4-10 X 3-1/2 GRADE 8 HEX BOLT
9 RT-2611 DISK SPRING CLAMP PLATE
10 BH-6325 5/8-11 X 2-1/2 GRADE 5 HEX BOLT
11 NLT-7510 3/4-10 TOP LOCK NUT
12 NLT-6311 5/8-11 TOP LOCK NUT
13 RD-4470 DISK GANG SPRING
14 BHY-7525 3/4-10 x 2-1/2 BOLT GD 8
15 RD-4895 SCRAPER MOUNT BRACKET
Item Part Number Description
16 RD-4842 DISK END SPACER
17 BU-5823 5/8-11 x 2 x 3 U-BOLT
18 LW-0063 5/8 LOCK WASHER
19
RD-4969
RD-4897
RD-4973
RD-4971
RD-4974
RD-4972
RD-4897
RD-4971
RD-4917
RD-4917
RD-4971
RD-4974
RD-4917
RD-4969
11 SCRAPER TUBE LT & RT 4112
12 SCRAPER TUBE LT & RT 4114
13 SCRAPER TUBE LT & RT 4116
9 SCRAPER TUBE LT & RT MAIN 4120
8 SCRAPER TUBE LT & RT WING 4120
7 SCRAPER TUBE RT WING 4120
12 SCRAPER TUBE LT & RT MAIN 4125 & 4130
9 SCRAPER TUBE LT & RT WING 4125
14 SCRAPER TUBE LT & RT WING 4130
14 SCRAPER TUBE LT & RT MAIN 4135
9 SCRAPER TUBE LT & RT INSIDE WING 4135
8 SCRAPER TUBE LT & RT OUTSIDE WING
4135
14 SCRAPER TUBE LT & RT MAIN/INSIDE
WING 4145
11 SCRAPER TUBE LT & RT OUTSIDE WING
4145
20 BU-1223 1/2 x 2 x 3 U-BOLT
21 LW-0050 1/2 LOCK WASHER
22 NH-5013 1/2-13 NUT
23 RD-4898 SCRAPER ARM
24 BC-3810 3/8-16 X 1 CARRIAGE BOLTS
25 NLT-3816 3/8-16 TOP LOCK NUTS
26 RD-4532 SCRAPER
27 QT-1005 BEARING HOUSING, TRUNNION
28 FW-0138 FLAT WASHER 1-3/8
29 QT-1146 BEARING HOUSING SPACER
30 QT-1056 BEARING 1-1/2 SQ
31 QT-1147 SNAP RING
32 QT-1145 BEARING ASSY. TRUNNION
33 RD-4900 HITCH PIN
34 RD-5076 TWIST CLIP
