McHale C430/C460/C470/C490 Bale Chopper
27
Machine lifting points (C460 shown)
4.10 Jacking guidelines
Ensure the machine is on flat solid ground and attached to a tractor. Apply the tractor
hand brake, switch off the tractor and remove the key, disconnect the hydraulics and
PTO. Use wheel chocks on the opposite wheel to secure against unexpected
movement. Suitable well maintained equipment shall be used to raise the machine.
Never go under the machine while it is raised off the ground. The jacking points are at
the rear of the machine. Only approach the machine with the jack from the rear, to
ensure that there is adequate working room. Ensure the jack makes solid contact with
the plate below the jacking point decal, before raising the machine off the ground.
WARNING: Do not rely solely on a hydraulic jack!
Ensure the machine is additionally supported with axle stands or
equivalent of suitable capacity. Never support the machine with props
that may break or crumble under continuous load.
