5.10 Lighting system
The 7-pin plug of the lighting system on the machine must be connected to the 7-pin
socket on the tractor.
Key:
m
t
Unladen mass of the tractor (kg)
m
a
Mass of machine and bale on the rear linkage (kg)
m
z
Front ballast (kg)
d Distance from centre of gravity of front ballast to front axle centre (m)
i Tractor wheelbase (m)
s
1
Distance from the rear axle centre to the centre of the lowest points of
the three point linkage (m)
s
2
Distance from the centre of the lowest points of the three point linkage
to the centre of gravity of the machine and bale (m)
WARNING: The above calculations are a guide only
Travelling over rough or sloping ground may require additional ballast
to ensure machine-tractor stability.
NOTE: Check lighting system before travelling on the road
Before travelling on a public road, the operator must ensure that the
complete (tractor and machine) lighting system is in a fully functioning
condition.
