McHale C430/C460/C470/C490 Bale Chopper
8
2.2 Front view
No. Machine function No. Machine function
1 Chute 8 Loading door
2 Distribution slide 9 Bale chamber
3 Hose carrier 10 Comb
4 Gearbox 11 Floor conveyor
5 PTO input shaft 12 Hydraulic section (inside cover)
6 Drawbar (C460/C470/C490) 13 Rotor
7 3-point linkage, CAT 2 (C430) 14 Fan
