McHale C430/C460/C470/C490 Bale Chopper
9
2.3 General dimensions & specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
2.4 Tractor attachment
Model C430 Linkage C460/C470/C490 Trailed
Transport length 2.64 m (104”)
4.5 m (177”) C460
5.0 m (197”) C470
6.0 m (236”) C490
Transport width 2.12 m (83”) 2.25 m (89”)
Transport height
(chute closed)
2.45 m (96”) 2.65 m (104”)
Unladen weight 1,800 kg (3,968 lbs)
2,220 kg (4,894 lbs) C460
2,450 kg (5,401 lbs) C470
2,900 kg (6,393 lbs) C490
Road speed (max) 40 km/h (25 mph) 40 km/h (25 mph)
Model C430 Linkage C460/C470/C490 Trailed
Tractor size (min) 110 kW 60 kW
Attachment 3-point linkage, CAT 2
Low drawbar / lower link arms
PTO speed 540 rpm
Lighting 12 V / 7-pin socket
Electrics 12 V, 20 A socket
Hydraulic systems Open-centre
Minimum pressure 180 bar (2,610 psi)
Minimum flow rate 20 l/min (4.54 gal/min) @ 180 bar (2,610 psi)
