McHale C430/C460/C470/C490 Bale Chopper
66
9.8 Comb adjustments
9.8.1 Adjusting the comb fingers
The clearance between the comb fingers and the disc edges of the rotor must be
between 2 and 6 mm. Ensure comb fingers and sections do not make contact.
9.8.2 Pre-cut comb cover
The comb cover has been pre-cut to allow operators seeking better visibility to cut out
one or two viewing holes if desired.
.
Comb cover
Comb Comb dividers
Rotor
Knife sectionsRotor disc edge
