McHale C430/C460/C470/C490 Bale Chopper
34
5.4 Preventing unauthorised use
To prevent unauthorised use, McHale recommend using the padlock and the locking
device provided. Both items are stored in the tool box on the machine and should be
fitted to the drawbar coupling when the machine is not in use.
Linkage attachments (Cat. 2 and Cat. 3)
Place lock out device on headstock pin
Secure with padlock through the linch pin hole
Linch pin can also be secured with the padlock to prevent loss
Once the padlock is locked, the machine should be secure
Place lock out device in between clevis
Thread pin through and secure with padlock in the linch pin hole
Linch pin can also be secured with the padlock to prevent loss
Once the padlock is locked, the machine should be secure
