McHale F5500 Baler
28
Knife release lever:
horizontal position-locked
vertical position-unlocked
(CST00118)
Keep hands out of the crush area between the roller
and chassis rail
(CST00120)
Maximum hydraulic pressure and maximum PTO
speed. This machine must not be connected to
hydraulic systems with pressure higher than 210 bar.
(CST00121) - 540 rpm PTO/gearbox speed
(CST00814) - 1,000 rpm PTO/gearbox speed
Disconnect machine feed line and turn off the control
box during road use. Read the operation instruction
manual before proceeding.
(CST00135)
Net amount setting decal
(CST00136)
Do not step under the raised tailgate or attempt to do
any adjustments on the machine while the tailgate is
raised before the safety lock is applied. To avoid injury
stay clear of the tailgate while it is being raised and
lowered. Also ensure that bystanders are outside the
‘Danger Zone’ before operating the tailgate.
(CST00140)
