13
Figure 14– Browser Setup Menu
In this manual, submenus are denoted in the style:
Setup>SPEAKERS>Floor Layout
which means from the Setup menu choose the
SPEAKERS submenu then choose Floor Layout.
Entering Setup
To enter Setup mode using the Vacuum Fluorescent
Display (VFD):
• Press and hold the Left Knob for Two
seconds and then release
(A short push of the Left Knob will bring up Trim
settings. See “The Trim Menu” on page 27.)
Determining the IP Address
Setup>Network>Information>IP Address
• In Setup Mode, turn the Left Knob and scroll
to Network
• Select by pushing the left knob
• Scroll to Information and select
• Scroll to IP Address and select
• Note the IP Address
Exing Setup
To exit Setup, push and hold the Left Knob for two
seconds.
To return to a previous menu, scroll down to last
menu choice which will be MENU BACK. Select
MENU BACK by pushing and releasing the LEFT
KNOB. On the top most menu, the last menu choice
will be MENU OFF which will exit Setup.
The Setup Menu will time out after 30 seconds of
no user input.
Navigang Setup with the
Remote Control
0
AM PRESET
FM
INPUT
VOL
BAND
SELECT
AM
OUTPUT2
OUTPUT 1
LEVEL UP
MENU
INFO
LEVEL DN
TRIM
GUIDE
EXIT
MODE
SETUP
Enter the Setup Menu by pressing the Setup button
(A). The Setup Button has a blue circle on it.
You can scroll through the Setup options by pressing
the Up Arrow (B) or Down Arrow (C) on the silver
ring.
Push the SELECT button (G) to choose an option to
change.
Use the Left Arrow (D) and Right Arrow (E) on the
silver ring to change values for the selected Setup
option. The new value will be saved automatically.
You may use the Up Arrow (B) or Down Arrow (C)
to view another option.
The Mode/Exit button (F) will navigate up a menu
level or exit from the top menu just as selecting
MENU BACK or MENU OFF will.
The Setup Menu will close after 30 seconds of
inactivity.
A
B
D
C
E
F
Figure 15– Setup using the
Remote Control
G
