McIntosh MX100

28
Mode
A Surround Mode can be set for each Input using the
Trim Menu.
From the Mode submenu the following options are
available:
• AUTO
• MOVIE
• MUSIC
• GAME
• THROUGH
MOVIE, MUSIC and GAME are variables that
are assigned a specifc Surround Mode choice. The
Surround Modes that are used for MOVIE, MUSIC
and GAME options are assigned in Setup. The
default for each option is AUTO. Other options are
Dolby Surround, DTS Neural:X:X, Multi-Channel
Stereo, Stereo and Through. For more information
about these options see “Surround Mode” on page
14.
To assign a mode to an Input:
• Press and Release the Left Knob (or press
and release the TRIM GUIDE button on the
Remote Control)
• Rotate the Left Knob until MODE is displayed
(or press the Down Arrow on the silver ring of
the Remote Control)
• Press and release the Left Knob (Press and
release the SELECT button)
• Rotate the Left Knob until the desired Input is
displayed (Use the Up or Down arrows to nd
the desired Input)
• Rotate the Right Knob scroll through the
Surround Modes (use the Left and Right
Arrows to scroll the Surround Modes)
• Press and Hold the Left Knob for two seconds
to leave the Trim menu or Rotate the Left
Knob for another Input to assign a Surround
Mode (press the MODE/EXIT button twice to
leave the Trim Menu or wait until it times-out)
A quick way to change the current Input’s Surround
Mode is to use the MODE button on the outer ring
of the Remote Control. Pressing the MODE button
will cycle throught the Surround Modes. Stop on
your choice. The Display will time-out in a few
seconds and your choice will be saved.
Supported HDMI Signals
The MX100 supports the HDCP copyright protection
system. For proper playback the connected video
device must also support HDCP. Here are supported
video signals:
• 480i
• 480p
• 576i
• 576p
• 720p 60/50Hz
• 1080i 60/50Hz
• 1080p 60/50/24Hz
• 4K 60/50/30/25/24Hz
The MX100 can play the following audio formats via
HDMI:
2-channel Linear
PCM
2-channel, 32 kHz – 192 kHz,
16/20/24 bit
Multi-channel
Linear PCM
7.1-channel, 32 kHz – 192 kHz,
16/20/24 bit
Bitstream Dolby Digital / DTS / Dolby
Atmos / Dolby TrueHD /Dolby
Digital Plus / DTS:X / DTS-HD
Master Audio /DTS-HD High
Resolution Audio / DTS Express
