2-2
Unità Esterna [Serie 5SLY10/15D/DR]
Tutte le dimensioni sono in mm/(pollici)
490(19,3)
574(22,6)
13(0,5)
311(12,2)
29,5(1,2)
285(11,2)
8(0,3)
12(0,5)
765(30,1)
63(2,5)
550(21,7)
105,5(4,2)
Acson IM-WMJ-0109(0)-MacQuay_IT.2 2 2009-4-8 9:13:10
