1-2
Outdoor Unit [5SLY10/15D/DR]
765(30.1)12(0.5) 63(2.5)8(0.3)285(11.2)
490(19.3)
574(22.6)
105.5(4.2)
13(0.5)
29.5(1.2)
311(12.2)
550(21.7)
All dimensions are in mm / (in)
Acson IM-WMJ-0109(0).indd 2 2009-4-8 9:10:11
