Schematics & Part Numbers
Spare Part Numbers
Part Numbers
Description
Part Number
Offset Cam Adjuster (Camber & Toe Adjuster) YDZS030
Poly Bush YJJJ016
Steel Bush Insert YZCN002
Grease Nipple 6mm Metric
12” Megahub RHS complete (Backing plate, linings &
drum with 14mm studs and nuts)
YZCQ032
12” Megahub LHS complete (Backing plate, linings &
drum with 14mm studs and nuts)
YZCQ031
12” Megahub Drum Only 14mm Studs YZCQ033
12” LHS Backing Plate Only (With linings) DM00025
12” RHS Backing Plate Only (With linings) MJFCX003
14mm Wheels Stud YHJL110
14mm Wheel Nut YZCQ029
M38 Castle Nut M38 Metric LGPJ002
90mm Bearing Dust Cap (3 ³⁵/₆₄”) MDC Specific CSWH001
Wheel Bearing (Timken) 25590
Bearing Race 25590
Bearing Seal Metric 55 x 85 x 12mm 2 ¹¹/₆₄” x 3 ¹¹/₃₂” x ¹⁵/₃₂”
